4CX1000A

Posted by tntadmin
$725.00
SKU: 4CX1000A

4CX1000A

Call or email first to confirm stock prior to entering an order(info@newtube.com)





The 4CX1000A  /  8168 Vacuum tube is a high current, low voltage tetrode used in audio amplifiers.



Electrical specifications for the 4CX1000A  /  8168 Vacuum tube:


Filament                                                                 Oxide Coated

Voltage                                                                            6 Volts

Current                                                                             9Amps

Plate Dissipation                                                        1,000 Watts

Grid Dissipation                                                               0 Watts

Maximum frequency for full rating CW                          110 MHz

Capacitance  Grounded Cathode connection:

Input                                                                                    81 pF

Output                                                                              11.8 pF

Feedback                                                                           .01 pF



Mechanical specifications for the 4CX1000A  /  8168 Vacuum tube:

 Cooling                                                                      Forced Air

Length                                                                              4.80 in.

Diameter                                                                          3.37 in.

Weight                                                                               27 oz.



Price: $725.00
