SKU: 4CX1500B


Call or email first to confirm stock prior to entering an order(info@newtube.com)

 Currently on back order tubes are due in stock 1/28/11 or sooner

The 4CX1500B  /  8660 Vacuum tube is used in RF & audio linear amplifiers.


Electrical specifications for the 4CX1500B  /  8660  Vacuum tube:

Filament                                                                  Oxide Coated

Voltage                                                                             6  Volts

Current                                                                          10  Amps

Plate Dissipation                                                          1500 Watts

Grid Dissipation                                                                 1 Watts

Maximum frequency for full rating CW                            110  MHz

Plate Voltage (max)                                                               3 KV

Plate Current (max)                                                           .90 Amps


Mechanical specifications for the 4CX1500B  /  8660 Vacuum tube:


Cooling                                                                         Forced Air

Length                                                                                4.80  in.

Diameter                                                                            3.37  in.

Weight                                                                                  27 oz.


Price: $775.00
