3CX15,000A3

Posted by tntadmin
$2,195.00
SKU: 3CX15,000A3

3CX15,000A3

Call or email first to confirm stock prior to entering an order(info@newtube.com)











The 3CX15000A3  /  3CX15,000A3 Vacuum tube is used in Industrial heating, Communications and Broadcasting applications.

Electrical specifications for the 3CX15000A3  /  3CX15,000A3 Vacuum tube:

Filament                                                 Thoriated Tungsten mesh

Voltage                                                                          6.3 Volts

Current                                                                       160 Amps

Amplification factor                                                                20

Plate Dissipation                                                    15,000 Watts

Grid Dissipation                                                          500 Watts

Maximum frequency for full rating CW                           100 MHz



Mechanical specifications for the 3CX15000A3  /  3CX15,000A3 Vacuum tube:



Cooling                                                                       Forced Air

Base                                                                                Coaxial

Length                                                                              8.75 in.

Diameter                                                                          7.05 in.

Weight                                                                              12 lbs.

Price: $2,195.00
