$389.00
SKU: JD1301A
Price includes shipping. Good for Domestic USA locations only not good for Hi or Alaska. All units are shipped Fedex Ground and must be signed for upon delivery. Not sure about this model? Have questions? Email us and we'll be glad to consult you or address your concerns, no question is too bothersome, email us so we can help you!! info@newtube.com When placing your order do not specify shipping method.
Please read our return policy on Jolida items in "Policies"
Model JD 1301A
Construction Details and Features:
- Fully Integrated Stereo Amplifier: Input 500mV driving 30 watts.
- Multiple Inputs: Front mounted selector switch-CD, Tape Recorder, Tuner and Aux (for TV, DVD Player, VCR or Computer).
- State of the Art Components: ALPS audio potentiometer, gold plated RCA input jacks
Technical Specifications:
|
Rated Output Power:
|
30 W per channel at 8 ohms, 22Hz to 20KHz
|
|
Frequency Response:
|
(at 1 watt into 8 ohms) 5Hz to 100KHz + 1dB
|
|
Bandwidth:
|
22Hz to 20kHz + 3dB; 0dB 30 W 1KHz
|
|
Distortion THD:
|
Less than 0.1% at 30 W output, 25Hz to 18KHz
|
|
Input Impedance:
|
47Kohms
|
|
Input Sensitivity:
|
500mV at 1KHz and 8 ohms for 30 watt output
|
|
Noise and Hum:
|
90dB below rated output
|
|
Tube Complement:
|
2 pcs. 12AX7 for the preamplifier
|
|
Power Requirements:
|
110V-120 VAC 60Hz 180 watts-standby, 450 watts maximum (220 VAC 50Hz option).
|
|
Dimensions:
|
7 inches wide by 6 inches deep by 4 inches high.
|
|
Weight:
|
8 pounds (3.65 Kg) net, approximately 11 pounds (5 Kg) packaged.
|
|
Warranty:
|
One year limited parts and labor. Six months or 1000 hours whichever comes first on Jolida Tubes.
|
|
Fuse:
|
110 - 120 VAC, 1 Amp Fast Blo; 200 - 240 VAC, 1 Amp Fast Blo
|
Price: $389.00
