$595.00
SKU: JD1701RC
Price includes freight (Domestic USA locations only not good for Hi or Alaska ) do not select any shipping method when ordering . All Jolida units are shipped via Fedex ground with signature required upon receipt. .Not sure about this model? Have questions? Email us and we'll be glad to consult you or address your concerns, info@newtube.com
Jolida now offers the JD1701A in a Remote control format ( the non remote of JD1701A has been discontinued)
Technical Specifications:
|
Rated Output Power:
|
50 W per channel at 8 ohms, 22Hz to 19KHz
|
|
Frequency Response:
|
(at 1 watt into 8 ohms) 5Hz to 100KHz + 1dB
|
|
Bandwidth:
|
22Hz to 19kHz + 3dB; 0dB 50 W 1KHz
|
|
Distortion THD:
|
Less than 0.1% at 50 W output, 22Hz to 18KHz
|
|
Input Impedance:
|
47Kohms
|
|
Input Sensitivity:
|
500mV at 1KHz and 8 ohms for 50 watt output
|
|
Noise and Hum:
|
90dB below rated output
|
|
Tube Complement:
|
2 pcs. 12AX7 for the preamplifier.
|
|
Power Requirements:
|
110V-120 VAC 60Hz 180 watts-standby, 450 watts maximum (220 VAC 50Hz option).
|
|
Dimensions:
|
17 inches wide by 13 inches deep by 4 inches high high.
|
|
Weight:
|
30 pounds net, approximately 33 pounds packaged.
|
|
Warranty:
|
18 months limited parts and labor. Six months or 1000 hours whichever comes first on Jolida Tubes.
|
|
Fuse:
|
110 - 120 VAC, 3.5 Amp Fast Blo; 200 - 240 VAC, 3.5 Amp Fast Blo
|
Price: $595.00
