The JD502CRC has E-Z Bias,front panel jack for ipod,bypass function and more.
JD 502CRC Integrated Stereo Tube Amplifier with Remote Control
The Design Challenge: Build a stereo tube amplifier with a sound quality that equals or exceeds the best in high end audio equipment. Included were two major criteria, make sure designs are reliable and can be sold at value prices. The Engineering Result: An integrated stereo tube amplifier that can be hooked up directly to a CD player and two speakers. The Sound: High end audio tube performance at a value price.
Construction Details and Features:
- Fully Integrated Stereo Amplifier: Input 600mV driving 60 watts, maximum 85 watts output.
- Remote Control
- Multiple Inputs: Front mounted selector switch-CD, Tape Recorder, Tuner and Aux. (for TV, VCR or Computer
- Bypass Switch: This feature enables the amp to be use as a power or integrated amplifier.
- Custom Wound Audio Transformers with a core of German grain oriented silicon steel. 15th generation proprietary design. Secondary can be configured for a 4 ohm or 8 ohm load.
- Easy bias with top panel bias testing terminal with bias adjustment controls.
- State of the Art Components: Blue ALPS audio potentiometer, gold plated RCA input jacks and one set of XLR.
- Fixed and Variable Outputs.
Technical Specifications:
| Maximum Power Output: | 85 W per channel at 8 ohms, 1KHz |
| Rated Output Power: | 60 W per channel at 8 ohms, 25Hz to 60KHz |
| Frequency Response: | (at 1 watt into 8 ohms) 8Hz to 130KHz + 1dB |
| Bandwidth: | 15Hz to 80KHz + 3dB; 0dB 60 W 1KHz |
| Distortion THD: | Less than 1% at 20 V output, 28Hz to 15KHz |
| Input Impedance: | 100Kohms |
| Input Sensitivity: | 600mV at 1KHz for 60 watt output |
| Output Impedance: | 4 ohms and 8 ohms |
| Negative Feedback: | Less than 5 dB |
| Noise and Hum: | 85dB below rated output |
| Tube Complement: | 2 matched pairs (4) of 6550/KT88 power output; 2 pcs. 12AX7A/ECC83 pre-amplifier; 2 pcs. 12AT7/ECC81 power drivers. |
| Power Requirements: | 110V-120 VAC 60Hz 180 watts-standby, 450 watts maximum (220 VAC 50Hz option) |
| Dimensions: | 17 inches (43cm) wide by 15 inches (38cm) deep by 7.5 inches (19 cm) high |
| Weight: | 39 pounds (18 Kg) net, approximately 46 pounds (21 Kg) packaged |
| Warranty: | Two year limited parts and labor. One year or 1000 hours whichever comes first on Jolida Tubes |
| Fuse: | 110 - 120 VAC, 6.3 Fast Amp Blo; 200 - 240 VAC, 3 Amp Fast Blo |
